Electronic Loads DC Electronic Loads ITECH IT-M3900B Series – Regenerative Power System
ITECH

ITECH IT-M3900B Series – Regenerative Power System

IT-M3900B regenerative power system features two units-in-one: a bidirectional DC power supply, and an independent regenerative DC electronic load. One-button-switch between source and load mode, a unique and decisive feature for the users that work in different applications such as battery, PV energy storage, electric vehicle, Green energy and some ATE fields.

Downloads
Categories: DC Bidirectional Power Supplies, DC Electronic Loads, DC Power Supplies, Power Supplies
Share:
  • Description
  • Additional information
  • Downloads
Description
  • 2 in 1 unit – a bidirectional power supply and a regenerative load
  • One button switch between source and load on front panel
  • Compact design, 1U@6kW, 2U@12kW
  • Voltage range: 10~1500V
  • Current range: -720A~1020A
  • Power range: ±12kW
  • Bidirectional energy flow between the DUT and the grid, current seamless switching
  • Master/slave parallel connection with patented technology – keep good performance while power extension*1
  • Efficient power regeneration –  reduce cost of electricity and cooling
  • CC/CV priority
  • Adjustable output impedance
  • Battery charge and discharge test
  • Battery simulation
  • Partial pre-compliant with LV123, LV148, DIN40839,ISO-16750-2, SAEJ1113-11,LV124 and ISO21848 automotive testing standards
  • Support solar panel I-V curves simulation*2
  • Slope of voltage, current and power is settable
  • Simulation of dynamic driving conditions, up to 10 million points
  • 8 operation modes under Source mode: CC/CV/CW/CR/CC+CV/CV+CR/CR+CC/CC+CV+CW+CR
  • Multiple protection: OVP / ±OCP / ±OPP / OTP /voltage transient drop protection/anti-islanding/power grid detection/pre-charge
  • Built-in USB/CAN/LAN/digital IO interfaces, Optional GPIB/Analog&RS232
  1. If parallel connection >6 units, pls. contact ITECH for details
  2. Not available for 10V models
Additional information
Approvals

SPE-1000

Downloads
  • ITECH IT-M3900B Series Datasheet
